Venom 400 Control Module

Postby jotcrx » January 19th, 2013, 4:22 pm

Venom 400 control module - not sure if they even make these anymore. It does work really well by "tricking" the engine that there is more load on the engine than there actuall may be to get to the OEM fuel and timing curves for more agressive driving. Works best at midrange RPMs, around 3000....

1987 Integra RS-R
1.6L DA1 w/4 spd Auto

User avatar

MugenBOI
Legit G1Tegger
Posts: 282
Joined: September 18th, 2012, 2:15 pm
Location: Santa Maria,Ca CENRTAL COAST

Re: Venom 400 Control Module

Postby MugenBOI » January 19th, 2013, 6:07 pm

nice carpet lol


Mr NW Classic

Re: Venom 400 Control Module

Postby Mr NW Classic » January 20th, 2013, 2:55 am

I like these, how do they perform sir?


Topic Author
jotcrx
G1 n00b
Posts: 63
Joined: September 14th, 2012, 8:36 pm
Location: Summerville, SC

Re: Venom 400 Control Module

Postby jotcrx » January 20th, 2013, 4:04 am

MugenBOI wrote:nice carpet lol


Its new :)
1987 Integra RS-R
1.6L DA1 w/4 spd Auto


Topic Author
jotcrx
G1 n00b
Posts: 63
Joined: September 14th, 2012, 8:36 pm
Location: Summerville, SC

Re: Venom 400 Control Module

Postby jotcrx » January 20th, 2013, 4:05 am

Mr NW Classic wrote:I like these, how do they perform sir?


Very well....with my auto teg, I can definitely feel the difference it makes with it switched on...more bottom end grunt :)
1987 Integra RS-R
1.6L DA1 w/4 spd Auto


Mr NW Classic

Re: Venom 400 Control Module

Postby Mr NW Classic » January 20th, 2013, 8:19 am

Where do you find them at? Any leads?


Topic Author
jotcrx
G1 n00b
Posts: 63
Joined: September 14th, 2012, 8:36 pm
Location: Summerville, SC

Re: Venom 400 Control Module

Postby jotcrx » January 20th, 2013, 3:26 pm

Mr NW Classic wrote:Where do you find them at? Any leads?


It got it back in 2001.
1987 Integra RS-R
1.6L DA1 w/4 spd Auto


Mr NW Classic

Re: Venom 400 Control Module

Postby Mr NW Classic » January 20th, 2013, 6:13 pm

Damn thats what I thought. lol


thebranded
Posts: 126
Joined: May 9th, 2005, 1:19 pm
Location: Sydney, Australia

Re: Venom 400 Control Module

Postby thebranded » January 20th, 2013, 10:33 pm

How is it connected to the ECU?
Rover 416i aka Honda aka Acura

Suspension: Illumi's all round, 24mm torsions (waiting to be installed) Cusco front strut bar
Intake: K&N Drop in filter
Exhurst: 2" SS 75% parts aquired.


Topic Author
jotcrx
G1 n00b
Posts: 63
Joined: September 14th, 2012, 8:36 pm
Location: Summerville, SC

Re: Venom 400 Control Module

Postby jotcrx » January 21st, 2013, 4:43 am

thebranded wrote:How is it connected to the ECU?


12v+
Ground
TPS
MAP

Here is the wiring manual...http://www.venom-performance.com/manual/Venom_400_User's_Manual.pdf

I just tapped the wires right next to the connector going into the ECU as it was easier to get to all four wires I needed and I had room to mount the control module next to the ECU under the seat.
1987 Integra RS-R
1.6L DA1 w/4 spd Auto


thebranded
Posts: 126
Joined: May 9th, 2005, 1:19 pm
Location: Sydney, Australia

Re: Venom 400 Control Module

Postby thebranded » January 21st, 2013, 5:10 am

cheers mate, very cleanly done!
Rover 416i aka Honda aka Acura

Suspension: Illumi's all round, 24mm torsions (waiting to be installed) Cusco front strut bar
Intake: K&N Drop in filter
Exhurst: 2" SS 75% parts aquired.


Eec4tuner
G1 n00b
Posts: 19
Joined: September 10th, 2012, 7:15 pm

Re: Venom 400 Control Module

Postby Eec4tuner » January 22nd, 2013, 6:42 am



Mr NW Classic

Re: Venom 400 Control Module

Postby Mr NW Classic » January 22nd, 2013, 8:04 pm

Ouch! $322!


Topic Author
jotcrx
G1 n00b
Posts: 63
Joined: September 14th, 2012, 8:36 pm
Location: Summerville, SC

Re: Venom 400 Control Module

Postby jotcrx » January 22nd, 2013, 11:29 pm

Fortunately for me I had a friend who worked at Venom and got me all of my Venom stuff for gratis, hence all of the Venom products on my Teg. This was back in the day when manufacturers would sponsor you before the economy tanked :)
1987 Integra RS-R
1.6L DA1 w/4 spd Auto


Mr NW Classic

Re: Venom 400 Control Module

Postby Mr NW Classic » January 24th, 2013, 2:04 am

Let me know if you see another pop up for cheaper.


thebranded
Posts: 126
Joined: May 9th, 2005, 1:19 pm
Location: Sydney, Australia

Re: Venom 400 Control Module

Postby thebranded » January 24th, 2013, 10:42 pm

when activated, this simulates that the engine is on a higher load that it actually is and there for the ECU uses a different fuel map?

Couldnt you DIY something to modify the map and tps sensors?
Rover 416i aka Honda aka Acura

Suspension: Illumi's all round, 24mm torsions (waiting to be installed) Cusco front strut bar
Intake: K&N Drop in filter
Exhurst: 2" SS 75% parts aquired.

User avatar

g1_teg_lover
G1 n00b
Posts: 86
Joined: March 25th, 2005, 7:02 am
Location: Virginia
Contact:

Re: Venom 400 Control Module

Postby g1_teg_lover » June 9th, 2013, 8:48 pm

Seems to sound like the power/econ switch that I've seen in a few older Mazda's. Those switches seemed to adjust the readings from the MAP and TPS sensors with what looked to be a few resistors (either adding to or subtracting, I didn't bother to do a full trace on the circuit), tricking the ECU into squirting more fuel (and adjusting the timing more then likely).

Not saying that the Venom module is anything like that however (don't have one and haven't seen the innards to be sure of how it's actually doing what it does). I'd be sure that the guys who put the R&D into the module however did figure out the proper way to do it.
